Nhà Sản phẩmRJ11 RJ12 RJ45 không có bộ biến áp59 SeriesRJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G
RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G
RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G
Liên hệ với bây giờ

RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G

Số lượng đặt hàng tối thiểu : 1 mảnh Giá bán : Please contact us to get the latest price.
chi tiết đóng gói : Khay trong thùng carton Thời gian giao hàng : 10 ngày
Điều khoản thanh toán : T/T, D/P, D/A, L/C, Western Union, Moneygram Khả năng cung cấp : 100K PC/ngày
Nguồn gốc: Dongguan của Trung Quốc Hàng hiệu: DGKYD
Chứng nhận: RoHS/CE/UL/FCC/CE/ISO9001/ISO14001 Số mô hình: DGKYD59212188IWA1DY1G

Thông tin chi tiết
Tốc độ: MÈO 3/5/6 Cổng: cổng đôi
Khiên: KHÔNG Máy biến áp: không có máy biến áp
Gắn loại: Loại PCB Chốt cửa: Tab lên/xuống
Nhiệt độ hoạt động: -40 ° C ~+85 ° C. Chấm dứt: NHÚNG
Loại giao diện Jack & plug mô -đun: RJ45 không có biến áp loại: giắc cắm điện thoại
Màu sắc: Đen
Làm nổi bật:

RJ45 network port non variable filter

,

59 Series all plastic network interface

,

stacked RJ45 port no light

Mô tả sản phẩm

RJ45 Network Port 2X1 Stacked Built-in Non Variable Filter, No Light, All Plastic Network Interface DGKYD59212188IWA1DY1G
RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G
Product Specification Document
Key Features
  • Interface type: crystal head application: 10 / 100 / 1000BASE-T Ethernet
  • Type: RJ45 built in magnetics
  • Working frequency: high frequency characteristic: filtering, anti-interference
  • Working temperature: -40℃ to 85℃
  • Storage temperature: -40℃ to 85℃
  • Lead free soldering: wave soldering height up to 265℃
Technical Specifications
Part Number DGKYD59212188IWA1DY1G Brand DGKYD/OEM/ODM
Place of Origin Guangdong of China Certification RoHS/CE/FCC/CE/ISO9001/ISO14001
Product Type Connector-Modular Connector Style Jack
Jack Type RJ45 Connector Type Modular Jack
Latch Style Standard Latch TAB-UP/DOWN
Filter Without Filter LED Option Without LED
LED Color No Panel Stops With Panel Stops
Shielded No Applies To Printed Circuit Board
Performance Speed 10/100/1000 BASE-T/TX Suitable for welding type Reflowsolding(Alternative)
Port Configuration Single Ports Number of Positions 8
Jack Configuration 1X1 Terminals per Port 8
Shield Material Copper Alloy preplated with Nickel PCB Mounting Orientation Side Entry (Right Angle)
Contact Mating Area Plating Material Gold G/Fu Contact Base Material Phosphor Bronze
Solder Tail Contact Plating Material Tin-Lead over Nickel PCB Mounting Style Through Hole
Termination Method to PC Board Through Hole-Press-Fit Board Lock With/Without Board Lock
Housing Material PBT Polyester Housing Color Black
Housing Material Temperature Standard UL Flammability Rating UL 94V-0
RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 0 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 1 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 2 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 3 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 4 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 5 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 6 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 7 RJ45 network port 2X1 stacked built-in non variable filter, no light, all plastic network interface DGKYD59212188IWA1DY1G 8
Product Advantages
  • RJ45 full series of integrated circuit accessories, RJ45 network connector manufacturer direct supply
  • Business mode: Manufacturer
  • Delivery time: on time delivery, around two weeks
  • Multiple customization options available for LED indicators, shielding, coil ratio, magnetic circuits, contact plating, and housing materials
  • Products meet industry standards for electrical properties, mechanical properties, and environmental protection
Frequently Asked Questions
Q: Are you trading company or manufacture?
A: We are manufacture. Welcome to our factory.
Q: What about your lead time?
A: For products in stock, the goods will be delivered within 5-7 working days after payment. For customized products and products that are out of stock, the delivery time should be confirmed according to your order quantity.
Q: Can you provide samples? Are they free?
A: Yes. Usually we can provide 2-3 samples of standard products free for testing.
Q: Can I put my own logo on it?
A: Yes. As a manufacturer with 11-year OEM experience, we are fully capable of customizing products for you.
